Sash and Case Windows

Sash Balance 50/86

The Sash Balance 50/86 profile is a high-performance option in sash and case windows, designed for properties that prioritize maximum insulation and energy efficiency. Here are the main details and advantages of using this profile with double glazing:

Energy Efficiency: The 50/86 profile provides top-tier insulation, making it ideal for energy-conscious homeowners. Double glazing in this profile helps reduce heat transfer, significantly saving heating and cooling expenses.
Enhanced Noise Reduction: The greater depth and double glazing combine to offer superior soundproofing, making this profile an excellent choice for properties in busy or high-traffic areas.
Classic Aesthetic with Modern Performance: Despite its robust structure, the Sash Balance 50/86 maintains the timeless charm of traditional sash and case windows. It preserves the classic style while meeting modern insulation and noise-reduction requirements.
Durability and Structural Integrity: The 50 mm depth provides added stability, allowing the frame to support larger, heavier double-glazed units. This enhances the window’s durability and lifespan, even in harsh weather conditions.
Customization Options: The profile is available in various finishes and colors, allowing customization to suit the architectural style of heritage and contemporary buildings.

Frame Dimensions:

Frame depth: 134 mm
Frame width (outer): 86 mm
The sash depth is 50 mm

Materials:

Frame Material: Constructed from high-quality timber, treated for moisture resistance and durability.
Glazing type: Low-E glass, argon-filled, toughened and laminated glass options are available for added thermal performance and security.

Thermal Performance:

Double Glazing Compatibility: Allows for enhanced insulation, reducing heat loss and meeting modern energy standards.
Thermal Break Technology: Integrated thermal breaks to prevent cold bridging, further improving energy efficiency.

Weather Sealing:

Equipped with advanced weather seals to protect against drafts and water ingress, suitable for harsh weather conditions. resistance

Soundproofing:

Double glazing: Reduces sound by up to 32 dB, ideal for urban or noisy environments
86 mm frame width and double glazing provide excellent sound insulation, ideal for urban or high-noise areas

Ventilation Options:

Trickle Ventilation: Optional vents for controlled airflow.
Tilt Function: Allows safe ventilation without fully opening the sash.

Security Features:

Enhanced Locking Mechanisms: Reinforced locks for increased resistance to break-ins.
Safety Glass Options: Available with laminated or toughened glass for added impact resistance.

Finishes:

Available in multiple finishes, including natural wood stains, painted finishes, and custom RAL colors.
UV-resistant coatings for long-lasting color integrity.
